- 적용(Rating)
-
Parts & Discharge Size 32mm~ 150mm 토출량Capacity ~60㎥ 총양정Head ~600m 회전수rpm 3500rpm,1750rpm 회전방향Rotaion CCWClock wise(View from coupling end) 허용운전온도Temperature -10℃~200℃ 임펠러형식Impeller Type Enclosed 축봉방식Shaft Sealing MechanicalSeal
- 용도(Applications)
-
- 보일러 급수용 / Boiler feedwater
- 고온 응축수 회수용 / For hot condensate recovery
- 고압 세척용 / For high pressure cleaning
- 산업용, 순환급수용 / Industrial,cyclical water supply acceptance
- 세척기기용 / For washing machines
- 급수 및 가압설비용 / Water supply and pressurization equipment
- 부스터펌프 시스템용 / For booster pump system
- 적용(Rating)
-
Parts & Discharge Size 32mm 40A/Bmm 50mm 65mm 토출량 Capacity 9㎥/hr 14/18㎥/hr 27㎥/hr 44㎥/hr 총양정 Head
225m 210/190m 215m 175m 회전수 rpm 3500rpm 회전방향 Rotaion Clock wise(View from coupling end) 허용운전온도 Temperature -10℃ ~ 180℃ 임펠러형식 Impeller Type Enclosed 플랜지 Flange 호칭압력 Suc. KS 10Kgf/㎠ Dis. KS 30Kgf/㎠ 가스켓자리 FF / RF 노즐방향 Bottom Suction / Side Discharge 축봉방식 Shaft Sealing Mechanical Seal
